CC0402KRX7R7BB103
RoHS
RoHS compliant
RoHS compliantPackage 0402 (1005 Metric)
Category Capacitors / Ceramic Capacitors
Description
0402 (1005Metric) CC 16V 10000pF ±10% X7R
PDF
/
Buying Options
Total Price: USD $0.09
Unit Price: USD $0.088
≥1 USD $0.088
≥10 USD $0.0132
≥100 USD $0.007744
≥500 USD $0.005984
≥1000 USD $0.004488
≥3000 USD $0.00352
Inventory: 125004
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Thickness 558.8μm
Thickness (Max) 0.022 0.55mm
Width 0.5mm
Length 1mm
Height 550μm
Technical
Halogen Free Halogen Free
Dissipation Factor 3.5 %
Voltage 16V
Insulation Resistance 100GOhm
Multilayer Yes
Temperature Characteristics Code X7R
Case Code (Imperial) 0402
Case Code (Metric) 1005
Voltage - Rated AC 16V
Depth 500μm
Packing Method TR, Paper, 7 Inch
Voltage - Rated DC 16V
Capacitance 10000pF
Applications General Purpose
Terminal Finish Matte Tin (Sn) - with Nickel (Ni) barrier
Temperature Coefficient X7R
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Tolerance ±10%
Size / Dimension 0.039Lx0.020W 1.00mmx0.50mm
Series CC
Published 2010
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C
Physical
Material Ceramic
Number of Pins 2
Terminal Shape WRAPAROUND
Package / Case 0402 (1005 Metric)
Mounting Type Surface Mount, MLCC
Mount Surface Mount
Supply Chain
Factory Lead Time 33 Weeks
