HIK102MBJEJ0KR
RoHS
/
Package Radial
Category Capacitors / Ceramic Capacitors
Description
High Voltage Ceramic Singlelayer DC Disc Capacitors, Class 2, Low Loss (0.5 %), 15 kVDC
PDF
/
Inventory: 5406
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount, Through Hole
Package / Case Radial
Number of Pins 8
Technical
Packaging Bulk
Tolerance 20%
Termination Radial
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Composition Ceramic
Voltage - Rated 15kV
Capacitance 1nF
Depth 8.4mm
Lead Pitch 12.5mm
Lead Diameter 800 μm
Turn On Delay Time 35 ns
Lead/Base Style Straight
Rise Time 60ns
Fall Time (Typ) 75 ns
Turn-Off Delay Time 115 ns
Continuous Drain Current (ID) 9.8A
Gate to Source Voltage (Vgs) 12V
Dimensions
Height Seated (Max) 23.0124mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Alternative Model
