ECC-T3F120JG
RoHS
/
Package Nonstandard SMD
Category Capacitors / Ceramic Capacitors
Description
Nonstandard SMD ECC 3kV 12pF ±5% SL/GP
PDF
/
Buying Options
Total Price: USD $2.77
Unit Price: USD $2.77495
≥1 USD $2.77495
≥10 USD $2.27715
≥100 USD $2.2059
≥500 USD $2.13465
≥1000 USD $2.06435
Inventory: 6203
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount, MLCC
Package / Case Nonstandard SMD
Terminal Shape WRAPAROUND
Technical
Operating Temperature -25°C~105°C
Packaging Tape & Reel (TR)
Published 2008
Series ECC
Size / Dimension 0.280Lx0.248W 7.10mmx6.30mm
Tolerance ±5%
JESD-609 Code e2
Feature High Voltage
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Temperature Coefficient SL/GP
Terminal Finish Tin/Silver (Sn/Ag)
Composition Ceramic
Applications General Purpose
HTS Code 8532.23.00.20
Capacitance 12pF
Voltage - Rated DC 3kV
Packing Method TR, EMBOSSED, 13 INCH
Reach Compliance Code unknown
Temperature Characteristics Code SL
Multilayer No
Rated (DC) Voltage (URdc) 3000V
Size Code 2218
Dimensions
Height 2.3mm
Length 5.7mm
Width 4.5mm
Thickness (Max) 0.110 2.80mm
Thickness 2.794mm
Compliance
RoHS Status RoHS Compliant
