ECC-A3D390JGE
RoHS
/
Package Radial, Disc
Category Capacitors / Ceramic Capacitors
Description
Radial Disc CERAMIC CAPACITOR KGE 2kV 39pF ±5% SL/GP
PDF
/
Inventory: 9836
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Radial, Disc
Terminal Shape WIRE
Dielectric Material CERAMIC
Technical
Operating Temperature -25°C~105°C
Packaging Bulk
Published 2002
Series KGE
Size / Dimension 0.276Dia 7.00mm
Tolerance ±5%
JESD-609 Code e3
Feature High Voltage
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Temperature Coefficient SL/GP
Terminal Finish Tin (Sn)
Lead/Base Style Formed Leads
Lead Style Formed Leads
Size Code 2822
Rated (DC) Voltage (URdc) 2000V
Multilayer No
Temperature Characteristics Code SL
Lead Spacing 0.295 7.50mm
Lead Length 20mm
Capacitor Type CERAMIC CAPACITOR
Lead Pitch 7.493mm
Reach Compliance Code unknown
Terminal Pitch 7.5mm
Voltage - Rated DC 2kV
Capacitance 39pF
HTS Code 8532.23.00.60
Applications General Purpose
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Width 5.5mm
Height Seated (Max) 0.433 11.00mm
Height 7mm
