RPE5C2A561J2P1B03B

Murata Electronics
RoHS
/
Package Radial
Category Capacitors / Ceramic Capacitors
Description Radial ceramic capacitor 100V 560pF 5% 30ppm/Cel ppm/C
PDF
/
Inventory: 8444
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Mount Through Hole
Package / Case Radial
Terminal Shape WIRE

Technical

Packaging Bulk
Tolerance 5%
JESD-609 Code e2
Pbfree Code yes
Number of Terminations 2
ECCN Code EAR99
Temperature Coefficient 30ppm/Cel ppm/°C
Terminal Finish Tin/Copper (Sn/Cu)
Max Operating Temperature 125°C
Min Operating Temperature -55°C
Composition Ceramic
HTS Code 8532.24.00.60
Capacitance 560pF
Voltage - Rated DC 100V
Depth 2.5mm
Lead Pitch 2.5mm
Lead Length 25mm
Dielectric C0G
Temperature Characteristics Code C0G
Multilayer Yes
Lead Diameter 500 μm
Dissipation Factor 0.8 %
Lead/Base Style Kinked

Dimensions

Height 3.5mm
Height Seated (Max) 5.0038mm
Length 5mm
Width 2.5mm

Compliance

Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Lead Free
