GRM155R71C103KA01D
RoHS
RoHS compliant
RoHS compliantPackage 0402 (1005 Metric)
Category Capacitors / Ceramic Capacitors
Description
GRM 0402 (1005Metric) Ceramic Capacitor 0.039Lx0.020W 1.00mmx0.50mm X7R ±10% 10000pF
PDF
/
Buying Options
Total Price: USD $0.01
Unit Price: USD $0.00665
≥1 USD $0.00665
≥10 USD $0.0057
≥100 USD $0.0057
≥500 USD $0.00475
≥1000 USD $0.00475
≥10000 USD $0.00475
Inventory: 58826
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Thickness 558.8μm
Thickness (Max) 0.022 0.55mm
Width 0.5mm
Length 1mm
Height 550μm
Technical
Voltage 16V
Multilayer Yes
Temperature Characteristics Code X7R
Case Code (Imperial) 0402
Case Code (Metric) 1005
Depth 500μm
Packing Method TR, PAPER, 7 INCH
Voltage - Rated DC 16V
Capacitance 10000pF
Applications General Purpose
Terminal Finish Matte Tin (Sn) - with Nickel (Ni) barrier
Temperature Coefficient X7R
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Not For New Designs
Pbfree Code yes
JESD-609 Code e3
Tolerance ±10%
Size / Dimension 0.039Lx0.020W 1.00mmx0.50mm
Series GRM
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C
Physical
Material Ceramic
Number of Pins 2
Terminal Shape WRAPAROUND
Package / Case 0402 (1005 Metric)
Mounting Type Surface Mount, MLCC
Mount Surface Mount
Supply Chain
Lifecycle Status NRND (Last Updated: 1 month ago)
