800B6R8CT500XT
RoHS
RoHS compliant
RoHS compliantPackage 1111 (2828 Metric)
Category Capacitors / Ceramic Capacitors
Description
ATC 800B 1111 (2828Metric) Ceramic Capacitor 0.110Lx0.110W 2.79mmx2.79mm C0G NP0 ±0.25pF 6.8pF
PDF
/
Buying Options
Total Price: USD $6.33
Unit Price: USD $6.32985
≥1 USD $6.32985
≥10 USD $5.19365
≥100 USD $5.0312
≥500 USD $4.86875
≥1000 USD $4.70725
Inventory: 1327
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Thickness 1.778mm
Thickness (Max) 0.070 1.78mm
Width 2.79mm
Length 2.79mm
Height 1.778mm
Technical
Multilayer No
Temperature Characteristics Code C0G
Dielectric C0G
Case Code (Imperial) 1111
Case Code (Metric) 2828
Packing Method TR
Voltage - Rated DC 500V
Capacitance 6.8pF
HTS Code 8532.23.00.20
Applications RF, Microwave, High Frequency
Composition Ceramic
Terminal Finish Tin (Sn) - with Nickel (Ni) barrier
Temperature Coefficient C0G NP0
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature High Q, Low Loss, Ultra Low ESR
JESD-609 Code e3
Tolerance ±0.25pF
Size / Dimension 0.110Lx0.110W 2.79mmx2.79mm
Series ATC 800B
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C
Physical
Terminal Shape WRAPAROUND
Package / Case 1111 (2828 Metric)
Mounting Type Surface Mount, MLCC
Mount Surface Mount
Supply Chain
Factory Lead Time 9 Weeks
