700B7R5CW500XT
RoHS
/
Package 1111 (2828 Metric)
Category Capacitors / Ceramic Capacitors
Description
1111 (2828Metric) ATC 700B 500V 7.5pF ±0.25pF C0G NP0
PDF
/
Inventory: 9378
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Thickness (Max) 0.102 2.59mm
Width 2.79mm
Length 2.79mm
Height 2.59mm
Technical
Multilayer Yes
Temperature Characteristics Code C0G
Dielectric C0G
Case Code (Imperial) 1111
Case Code (Metric) 2828
Reference Standard MIL-PRF-55681
Packing Method TR
Voltage - Rated DC 500V
Capacitance 7.5pF
HTS Code 8532.24.00.20
Additional Feature STANDARDS: MIL-PRF-55681, MIL-PRF-123
Applications RF, Microwave, High Frequency, Bypass, Decoupling
Composition Ceramic
Terminal Finish Tin/Lead (Sn/Pb) - with Nickel (Ni) barrier
Temperature Coefficient C0G NP0
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code no
Feature Low ESL
JESD-609 Code e0
Tolerance ±0.25pF
Size / Dimension 0.110Lx0.110W 2.79mmx2.79mm
Series ATC 700B
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C
Physical
Terminal Shape WRAPAROUND
Surface Mount YES
Package / Case 1111 (2828 Metric)
Mounting Type Surface Mount, MLCC
Supply Chain
Factory Lead Time 9 Weeks
