100B8R2BTN500XT
RoHS
RoHS compliant
RoHS compliantPackage 1111 (2828 Metric)
Category Capacitors / Ceramic Capacitors
Description
1111 (2828Metric) CERAMIC CAPACITOR Porcelain Superchip? ATC 100B 500V 8.2pF ±0.1pF P90
PDF
/
Buying Options
Total Price: USD $8.57
Unit Price: USD $8.57185
≥1 USD $8.57185
≥10 USD $7.03285
≥100 USD $6.8134
≥500 USD $6.59395
≥1000 USD $6.37355
Inventory: 1183
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Thickness 2.5908mm
Thickness (Max) 0.102 2.59mm
Width 2.79mm
Length 2.79mm
Height 2.59mm
Technical
Rated (DC) Voltage (URdc) 500V
Multilayer Yes
Temperature Characteristics Code BG
Capacitor Type CERAMIC CAPACITOR
Reference Standard MIL-PRF-55681
Packing Method TR
Capacitance 8.2pF
HTS Code 8532.24.00.20
Additional Feature STANDARDS: MIL-PRF-123, MIL-PRF-55681
Voltage - Rated 500V
Applications RF, Microwave, High Frequency, Bypass, Decoupling
Terminal Finish Tin (Sn)
Temperature Coefficient P90
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature High Q, Low Loss, Low ESL
JESD-609 Code e3
Tolerance ±0.1pF
Size / Dimension 0.110Lx0.110W 2.79mmx2.79mm
Series Porcelain Superchip? ATC 100B
Packaging Tape & Reel (TR)
Operating Temperature -55°C~175°C
Physical
Dielectric Material CERAMIC
Terminal Shape WRAPAROUND
Package / Case 1111 (2828 Metric)
Mounting Type Surface Mount, MLCC
Mount Surface Mount
Supply Chain
Factory Lead Time 10 Weeks
