100B820GT500XT
RoHS
RoHS compliant
RoHS compliantPackage 1111 (2828 Metric)
Category Capacitors / Ceramic Capacitors
Description
Porcelain Superchip? ATC 100B CERAMIC CAPACITOR 1111 (2828Metric) Ceramic Capacitor 0.110Lx0.110W 2.79mmx2.79mm P90 ±2% 82pF
PDF
/
Inventory: 1783
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Thickness 2.5908mm
Thickness (Max) 0.102 2.59mm
Width 2.79mm
Length 2.79mm
Height 2.59mm
Technical
Multilayer Yes
Temperature Characteristics Code P90
Capacitor Type CERAMIC CAPACITOR
Case Code (Imperial) 1111
Case Code (Metric) 2828
Packing Method TR
Voltage - Rated DC 500V
Capacitance 82pF
HTS Code 8532.24.00.20
Additional Feature MIL-PRF-55681, MIL-PRF-123
Applications RF, Microwave, High Frequency, Bypass, Decoupling
Terminal Finish Tin (Sn) - with Nickel (Ni) barrier
Temperature Coefficient P90
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature High Q, Low Loss, Low ESL
JESD-609 Code e3
Tolerance ±2%
Size / Dimension 0.110Lx0.110W 2.79mmx2.79mm
Series Porcelain Superchip? ATC 100B
Packaging Tape & Reel (TR)
Operating Temperature -55°C~175°C
Physical
Dielectric Material CERAMIC
Terminal Shape WRAPAROUND
Package / Case 1111 (2828 Metric)
Mounting Type Surface Mount, MLCC
Mount Surface Mount
Supply Chain
Factory Lead Time 9 Weeks
