100B300GTN500XT
RoHS
RoHS compliant
RoHS compliantPackage 1111 (2828 Metric)
Category Capacitors / Ceramic Capacitors
Description
Porcelain Superchip? ATC 100B CERAMIC CAPACITOR 1111 (2828Metric) Ceramic Capacitor 0.110Lx0.110W 2.79mmx2.79mm P90 ±2% 30pF
PDF
/
Inventory: 5280
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mounting Type Surface Mount, MLCC
Package / Case 1111 (2828 Metric)
Surface Mount YES
Terminal Shape WRAPAROUND
Dielectric Material CERAMIC
Technical
Operating Temperature -55°C~175°C
Packaging Tape & Reel (TR)
Series Porcelain Superchip? ATC 100B
Size / Dimension 0.110Lx0.110W 2.79mmx2.79mm
Tolerance ±2%
JESD-609 Code e3
Feature High Q, Low Loss, Low ESL
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Temperature Coefficient P90
Terminal Finish Tin (Sn)
Applications RF, Microwave, High Frequency, Bypass, Decoupling
Voltage - Rated 500V
Additional Feature STANDARDS: MIL-PRF-123, MIL-PRF-55681
HTS Code 8532.24.00.20
Capacitance 30pF
Packing Method TR
Reference Standard MIL-PRF-55681
Capacitor Type CERAMIC CAPACITOR
Temperature Characteristics Code BG
Multilayer Yes
Rated (DC) Voltage (URdc) 500V
Dimensions
Height 2.59mm
Length 2.79mm
Width 2.79mm
Thickness (Max) 0.102 2.59mm
Compliance
RoHS Status RoHS Compliant
