100A3R6BT150XT
RoHS
RoHS compliant
RoHS compliantPackage 0505 (1313 Metric)
Category Capacitors / Ceramic Capacitors
Description
Porcelain Superchip? ATC 100A CERAMIC CAPACITOR 0505 (1313Metric) Ceramic Capacitor 0.055Lx0.055W 1.40mmx1.40mm P90 ±0.1pF 3.6pF
PDF
/
Inventory: 3421
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Thickness (Max) 0.057 1.45mm
Width 1.4mm
Length 1.4mm
Height 1.45mm
Technical
Size Code 0606
Multilayer Yes
Capacitor Type CERAMIC CAPACITOR
Case Code (Imperial) 0505
Case Code (Metric) 1414
Reference Standard MIL-PRF-55681
Packing Method TR
Voltage - Rated DC 150V
Capacitance 3.6pF
HTS Code 8532.24.00.20
Additional Feature STANDARDS: MIL-PRF-123, MIL-PRF-55681
Applications RF, Microwave, High Frequency, Bypass, Decoupling
Terminal Finish Tin (Sn) - with Nickel (Ni) barrier
Temperature Coefficient P90
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature High Q, Low Loss, Low ESL
JESD-609 Code e3
Tolerance ±0.1pF
Size / Dimension 0.055Lx0.055W 1.40mmx1.40mm
Series Porcelain Superchip? ATC 100A
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C
Physical
Dielectric Material CERAMIC
Terminal Shape WRAPAROUND
Surface Mount YES
Package / Case 0505 (1313 Metric)
Mounting Type Surface Mount, MLCC
Supply Chain
Factory Lead Time 9 Weeks
