3690-16
RoHS
/
Package /
Category Prototyping, Fabrication Products / Card Extenders
Description
VECTOR ELECTRONICS 3690-16 EXTENDER CARD - PCB EDGE, 0.1" CENTER 30/43 POS
PDF
/
Buying Options
Total Price: USD $42.7
Unit Price: USD $42.6976
≥1 USD $42.6976
≥10 USD $40.25648
≥100 USD $39.03592
≥500 USD $35.376352
≥1000 USD $34.156672
≥3000 USD $32.936728
Inventory: 94
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 2 Weeks
Physical
Contact Material Bronze, Gold, Nickel
Contact Plating Gold
Material FR4 Epoxy Glass
Body Material Copper, Glass
Technical
Published 2003
Series Vectorbord?
Size / Dimension 6.500 x 4.500 165.10mmx114.30mm
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Type General Purpose
Number of Positions 28
Contacts 28 each side, 0.125 (3.18mm) Centers
Evaluation Kit Yes
Number of Contacts 56
Voltage - Rated AC 200V
Current Rating 5A
Voltage - Rated 300V
Compliance
Lead Free Contains Lead
Flammability Rating UL94 V-0
RoHS Status Non-RoHS Compliant
REACH SVHC No SVHC
Dimensions
Thickness 1.57mm
Height 114.3mm
