Package /
Category Connectors, Interconnects / Card Edge Connectors - Edgeboard Connectors
Description CONN EDGE DUAL FMALE 120POS .100
PDF
/
Inventory: 6368
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant

Dimensions

Length - Termination 0.44 inch
Card Thickness 0.062 1.57mm
Plating Thickness 30μin
Contact Finish Thickness 30.0μin 0.76μm

Technical

Flange Feature Top Mount Opening, Unthreaded, 0.125 (3.18mm) Dia
Number of Positions/Bay/Row 60
Read Out Dual
Card Type Non Specified - Dual Edge
Contact Resistance 30mOhm
Rated Current (Signal) 3A
Body Depth 0.431 inch
Body Breadth 0.4 inch
Number Of PCB Rows 2
Body Length or Diameter 6.875 inch
Reliability COMMERCIAL
Contact Finish Gold
Reference Standard UL
Number of Conductors ONE
Total Number of Contacts 120
Pitch 0.100 2.54mm
Contact Type Full Bellows
Subcategory Headers and Edge Type Connectors
Gender Female
Number of Rows 2
Color Blue
Number of Positions 120
Connector Type Full Bellows
Termination Solder
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
JESD-609 Code e3
Published 2015
Packaging Tray
Operating Temperature -65°C~125°C

Physical

Material - Insulation Polybutylene Terephthalate (PBT)
Mounting Type Through Hole
Mount Through Hole
Contact Material Phosphor Bronze

Supply Chain

Factory Lead Time 3 Weeks

Alternative Model
