ABC25DREF image
Favorite
ABC25DREF image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Card Edge Connectors - Edgeboard Connectors
Description CONN EDGE DUAL FMALE 50POS 0.100
PDF
/
Inventory: 5555
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 3 Weeks

Physical

Contact Material Beryllium Copper
Mount Panel
Mounting Type Panel Mount
Material - Insulation Polyphenylene Sulfide (PPS)

Technical

Operating Temperature -65°C~150°C
Packaging Tube
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Solder Eyelet(s)
Connector Type Full Bellows
Number of Positions 50
Color Green
Number of Rows 2
Gender Female
Subcategory Headers and Edge Type Connectors
Contact Type Full Bellows
Pitch 0.100 2.54mm
Total Number of Contacts 50
Reference Standard UL
Contact Finish Gold
Reliability COMMERCIAL
Body Length or Diameter 3.375 inch
Body Breadth 0.33 inch
Body Depth 0.431 inch
Rated Current (Signal) 3A
Card Type Non Specified - Dual Edge
Read Out Dual
Number of Positions/Bay/Row 25
Flange Feature Top Mount Opening, Floating Bobbin, 0.116 (2.95mm) Dia

Dimensions

Contact Finish Thickness 10.0μin 0.25μm
Plating Thickness 10μin
Card Thickness 0.062 1.57mm

Compliance

RoHS Status ROHS3 Compliant
Lead Free Lead Free
