ECJ-UVBPC105M
RoHS
/
Package 0504 (1410 Metric)
Category Capacitors / Capacitor Networks, Arrays
Description
0504 (1410Metric) ARRAY/NETWORK CAPACITOR ECJ 16V 1muF ±20% X5R
PDF
/
Buying Options
Total Price: USD $0.05
Unit Price: USD $0.04845
≥1 USD $0.04845
≥10 USD $0.0399
≥100 USD $0.03895
≥500 USD $0.038
≥1000 USD $0.0361
Inventory: 40001
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 0504 (1410 Metric)
Surface Mount YES
Terminal Shape WRAPAROUND
Dielectric Material Ceramic
Technical
Packaging Tape & Reel (TR)
Published 2005
Series ECJ
Size / Dimension 0.054Lx0.039W 1.37mmx1.00mm
Tolerance ±20%
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 4
ECCN Code EAR99
Temperature Coefficient X5R
Terminal Finish TIN
Voltage - Rated 16V
Capacitance 1μF
Packing Method TR, PAPER, 7 INCH
Number of Functions 2
Terminal Pitch 0.81mm
Operating Temperature (Max) 85°C
Operating Temperature (Min) -55°C
Capacitor Type ARRAY/NETWORK CAPACITOR
Number of Elements 1
Temperature Characteristics Code X5R
Rated (DC) Voltage (URdc) 16V
Circuit Type Isolated
Number of Capacitors 2
Dimensions
Height Seated (Max) 0.035 0.90mm
Length 1.37mm
Width 1mm
