GNM314R71E104MA11D
RoHS
/
Package 1206 (3216 Metric)
Category Capacitors / Capacitor Networks, Arrays
Description
1206 (3216Metric) ARRAY/NETWORK CAPACITOR GNM 25V 0.1muF ±20% X7R
PDF
/
Buying Options
Total Price: USD $1.58
Unit Price: USD $1.583357
≥1 USD $1.583357
≥200 USD $0.631505
≥500 USD $0.610499
≥1000 USD $0.599995
Inventory: 7477
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Length 3.2mm
Height Seated (Max) 0.037 0.95mm
Technical
Number of Capacitors 4
Circuit Type Isolated
Temperature Characteristics Code X7R
Number of Elements 1
Capacitor Type ARRAY/NETWORK CAPACITOR
Case Code (Imperial) 1206
Case Code (Metric) 3216
Depth 1.6mm
Terminal Pitch 800μm
Number of Functions 4
Packing Method TR, PAPER, 7 INCH
Voltage - Rated DC 25V
Capacitance 0.1μF
Min Operating Temperature -55°C
Max Operating Temperature 125°C
Terminal Finish Tin (Sn)
Temperature Coefficient X7R
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Tolerance ±20%
Size / Dimension 0.126Lx0.063W 3.20mmx1.60mm
Series GNM
Packaging Tape & Reel (TR)
Physical
Dielectric Material Ceramic
Terminal Shape WRAPAROUND
Package / Case 1206 (3216 Metric)
Mounting Type Surface Mount
Mount Surface Mount
