GNM314R61C105MA15D
RoHS
/
Package 1206 (3216 Metric)
Category Capacitors / Capacitor Networks, Arrays
Description
1206 (3216Metric) ARRAY/NETWORK CAPACITOR GNM 16V 1muF ±20% X5R
PDF
/
Inventory: 5099
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 1206 (3216 Metric)
Terminal Shape WRAPAROUND
Dielectric Material Ceramic
Technical
Packaging Cut Tape (CT)
Series GNM
Size / Dimension 0.126Lx0.063W 3.20mmx1.60mm
Tolerance ±20%
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
Termination SMD/SMT
ECCN Code EAR99
Temperature Coefficient X5R
Terminal Finish Tin (Sn)
Max Operating Temperature 85°C
Min Operating Temperature -55°C
Capacitance 1μF
Voltage - Rated DC 16V
Packing Method TR, PAPER, 7 INCH
Number of Functions 4
Terminal Pitch 800μm
Depth 1.6mm
Case Code (Metric) 3216
Case Code (Imperial) 1206
Capacitor Type ARRAY/NETWORK CAPACITOR
Number of Elements 1
Temperature Characteristics Code X5R
Circuit Type Isolated
Number of Capacitors 4
Dimensions
Height Seated (Max) 0.037 0.95mm
Length 3.2mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
