GNM2145C1H330KD01D
RoHS
/
Package 0805 (2012 Metric)
Category Capacitors / Capacitor Networks, Arrays
Description
0805 (2012Metric) ARRAY/NETWORK CAPACITOR GNM 50V 33pF ±10% C0G NP0
PDF
/
Buying Options
Total Price: USD $17.08
Unit Price: USD $17.07625
≥1 USD $17.07625
≥10 USD $14.01155
≥100 USD $13.5736
≥500 USD $13.13565
≥1000 USD $12.6977
Inventory: 1219
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 0805 (2012 Metric)
Terminal Shape WRAPAROUND
Dielectric Material Ceramic
Technical
Packaging Tape & Reel (TR)
Series GNM
Size / Dimension 0.079Lx0.049W 2.00mmx1.25mm
Tolerance ±10%
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
Termination SMD/SMT
ECCN Code EAR99
Temperature Coefficient C0G NP0
Terminal Finish Tin (Sn)
Max Operating Temperature 125°C
Min Operating Temperature -55°C
Capacitance 33pF
Voltage - Rated DC 50V
Packing Method TR, PAPER, 7 INCH
Number of Functions 4
Terminal Pitch 500μm
Depth 1.25mm
Capacitor Type ARRAY/NETWORK CAPACITOR
Dielectric C0G
Number of Elements 1
Temperature Characteristics Code C0G
Circuit Type Isolated
Number of Capacitors 4
Dimensions
Height Seated (Max) 0.028 0.70mm
Length 2mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
