GNM2145C1H100KD01D
RoHS
/
Package 0805 (2012 Metric)
Category Capacitors / Capacitor Networks, Arrays
Description
0805 (2012Metric) ARRAY/NETWORK CAPACITOR GNM 50V 10pF ±10% C0G NP0
PDF
/
Inventory: 1341
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Length 2mm
Height Seated (Max) 0.028 0.70mm
Technical
Number of Capacitors 4
Circuit Type Isolated
Voltage 50V
Temperature Characteristics Code C0G
Number of Elements 1
Dielectric C0G
Capacitor Type ARRAY/NETWORK CAPACITOR
Depth 1.25mm
Terminal Pitch 500μm
Number of Functions 4
Packing Method TR, PAPER, 7 INCH
Voltage - Rated DC 50V
Capacitance 10pF
Min Operating Temperature -55°C
Max Operating Temperature 125°C
Terminal Finish Tin (Sn)
Temperature Coefficient C0G NP0
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Tolerance ±10%
Size / Dimension 0.079Lx0.049W 2.00mmx1.25mm
Series GNM
Packaging Cut Tape (CT)
Physical
Dielectric Material Ceramic
Terminal Shape WRAPAROUND
Package / Case 0805 (2012 Metric)
Mounting Type Surface Mount
Mount Surface Mount
