7940006157
RoHS
RoHS compliant
RoHS compliantPackage /
Category Cables, Wires - Management / Cable Ties and Cable Lacing
Description
Electromechanical Relay DPDT 8A 24VDC 1.44KOhm Plug-In
PDF
/
Buying Options
Total Price: USD $15.79
Unit Price: USD $15.788935
≥1 USD $15.788935
Inventory: 5376
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Body Height 62mm
Length 78.5mm
Technical
Coil Release Voltage(DC) 2.4V
Coil Operate Voltage(DC) 16.8V
Coil Current(DC)-Max 0.017A
Coil Voltage(DC)-Max 24V
Coil/Input Supply Type DC
Relay Action MOMENTARY
Contact/Output Supply Type AC
Contact Voltage(AC)-Max 250V
Coil Power 500mW
Release Time 3 ms
Operate Time 7 ms
Contact (AC) Max Rating R Load 8A@250VAC
Coil Resistance 1.44kOhm
Contact Current(AC)-Max 8A
Relay Type POWER/SIGNAL RELAY
Throw Configuration DPDT
Termination Type CONNECTOR
Sealing IP20
Physical Dimension 78.5mm x 15.5mm x 62mm
Body Breadth 15.5 mm
Min Operating Temperature -40°C
Max Operating Temperature 70°C
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Published 2008
Packaging Bulk
Physical
Mount Plug-In
Contact Material Silver
Supply Chain
Factory Lead Time 10 Weeks
