PLT2S-M1
RoHS
RoHS compliant
RoHS compliantPackage /
Category Cables, Wires - Management / Cable Ties and Cable Lacing
Description
Brown 1000per Pkg Free Hanging (In-Line) PAN-TY? PLT (Wire/Cable Tie Type) 1.88 (47.75mm) 85C
PDF
/
Buying Options
Total Price: USD $0.13
Unit Price: USD $0.129114
≥1 USD $0.129114
Inventory: 1026
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Material Polyamide (PA66), Nylon 6/6
Weight 1.170268kg
Body Material Nylon
Technical
Packaging 1000 per Pkg
Published 2009
Series PAN-TY? PLT
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Color Brown
Depth 8mm
Tensile Strength 50 lbs (22.68 kg)
Wire/Cable Tie Type Standard, Locking
Bundle Diameter 1.88 (47.75mm)
Dimensions
Height 5.588mm
Length 188mm
Width 0.190 4.83mm
Length - Approximate 7.5
Length - Actual 0.617' 187.96mm 7.40
Compliance
RoHS Status ROHS3 Compliant
