2643000101
RoHS
RoHS compliant
RoHS compliantPackage /
Category Filters / Cable Ferrites
Description
Ferrite Core Bead 3.25mm 3.5mm Suppression Component
PDF
/
Buying Options
Total Price: USD $0.09
Unit Price: USD $0.088
≥1 USD $0.088
≥10 USD $0.044
≥100 USD $0.039424
≥500 USD $0.035552
≥1000 USD $0.026136
≥3000 USD $0.019008
Inventory: 133441
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mounting Type Free Hanging
Material 43
Weight 100mg
Technical
Packaging Bulk
Published 2010
Tolerance 20%
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination SMD/SMT
ECCN Code EAR99
Type Round
Terminal Finish MATTE TIN (SN) - WITH NICKEL (NI) BARRIER
Max Operating Temperature 125°C
HTS Code 8504.50.80.00
Packing Method TAPE AND REEL
Shielding Unshielded
Number of Functions 1
Frequency 300MHz
Physical Dimension D3.5XH3.25 (mm)/D0.138XH0.128 (inch)
Test Frequency 100MHz
Impedance 40Ohm
Design Solid
Impedance @ Frequency 40Ohm @ 100MHz
Outside Diameter 3.5 mm
Outer Dimension 0.138 Dia (3.51mm)
Dimensions
Diameter 3.5mm
Height 3.25mm
Length 0.128 3.25mm
Width 5.05mm
Diameter - Inside 1.3 mm
Diameter - Inner 0.051 Dia (1.30mm)
Compliance
RoHS Status ROHS3 Compliant
