LCBS-4-19 image
Favorite
LCBS-4-19 image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Hardware, Fasteners, Accessories / Board Supports
Description BRD SPT SNAP LOCK NYLON 1/4"
PDF
/
Buying Options
Total Price: USD $0.33
Unit Price: USD $0.3344
≥1 USD $0.3344
≥10 USD $0.28512
≥100 USD $0.23672
≥500 USD $0.222816
≥1000 USD $0.213136
≥3000 USD $0.189464
Inventory: 4530
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status RoHS Compliant

Dimensions

Mounting Panel Thickness 0.031 ~ 0.078 0.79mm ~ 1.98mm
Support Panel Thickness 0.062 1.57mm 1/16
Between Board Height 0.250 6.35mm 1/4
Length - Overall 0.984 25.00mm
Length 24.9936mm

Technical

Support Hole Diameter 0.157 (3.99mm)
Holding Type Snap Fit
Hole Diameter 3.9878 mm
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Feature Winged
Series Richco, LCBS-4
Published 2006

Physical

Mounting Hole Diameter 0.187 (4.75mm) 3/16
Material Nylon
Mounting Type Snap Lock

Supply Chain

Factory Lead Time 3 Weeks
