LCBS-20-01
RoHS
RoHS compliant
RoHS compliantPackage /
Category Hardware, Fasteners, Accessories / Board Supports
Description
LCBS-20-01, 31.7mm High Nylon Locking PCB Support Pillar with 4mm PCB Hole and 4.75mm Chassis Hole
PDF
/
Buying Options
Total Price: USD $0.46
Unit Price: USD $0.4576
≥1 USD $0.4576
≥10 USD $0.39248
≥100 USD $0.32736
≥500 USD $0.307648
≥1000 USD $0.294624
≥3000 USD $0.261976
Inventory: 1011
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 3 Weeks
Physical
Mount Chassis
Mounting Type Snap Lock
Material Nylon
Mounting Hole Diameter 0.187 (4.75mm) 3/16
Technical
Published 2006
Series Richco, LCBS
Feature Winged
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Hole Diameter 3.9878 mm
Holding Type Snap Lock
Support Hole Diameter 0.157 (3.99mm)
Dimensions
Height 28.6Mm
Length 50.292mm
Width 7.112Mm
Length - Overall 1.980 50.30mm
PCB Thickness 1.57mm
Between Board Height 1.250 31.75mm 1 1/4
Support Panel Thickness 0.062 1.57mm 1/16
Mounting Panel Thickness 0.031 ~ 0.078 0.79mm ~ 1.98mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
