LCBS-16M-01
RoHS
RoHS compliant
RoHS compliantPackage /
Category Hardware, Fasteners, Accessories / Board Supports
Description
BRD SPT SNAP LOCK NYLON 16MM
PDF
/
Inventory: 2528
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Mount PCB
Mounting Type Snap Lock
Material Nylon
Weight 49.895161g
Mounting Hole Diameter 0.187 (4.75mm) 3/16
Technical
Published 2008
Series LCBS-M
Feature Winged
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Hole Diameter 3.9878 mm
Holding Type Snap Lock
Support Hole Diameter 0.157 (3.99mm)
Dimensions
Height 16mm
Length 34.5948mm
Width 4mm
Length - Overall 1.362 34.60mm
Between Board Height 0.630 16.00mm
Support Panel Thickness 0.062 1.57mm 1/16
Mounting Panel Thickness 0.031 ~ 0.078 0.79mm ~ 1.98mm
Compliance
REACH SVHC No SVHC
RoHS Status RoHS Compliant
Lead Free Lead Free
