43160-0106
RoHS
/
Package SMC
Category Connectors, Interconnects / Blade Type Power Connectors
Description
Multipole Connector Number of Contacts:6
PDF
/
Buying Options
Total Price: USD $2.27
Unit Price: USD $2.26747
≥1 USD $2.26747
≥10 USD $2.139125
≥100 USD $2.018039
≥500 USD $1.903815
≥1000 USD $1.796041
Inventory: 6029
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Dimensions
Plating Thickness 80μin
Diameter 7.5mm
Technical
Glow Wire Compliant Compliant
Withdrawl Force-Min 4.448 N
Contact Pattern RECTANGULAR
Durability 25 Cycles
Dielectric Withstanding Voltage 5000VAC V
Polarization Key POLARIZED HOUSING
Body/Shell Style RECEPTACLE
Insulation Resistance 1GOhm
Contact Style BLADE PIN-SKT
Empty Shell NO
UL Flammability Code 94V-0
PCB Contact Pattern RECTANGULAR
Lead Pitch 7.5mm
Number Of PCB Rows 2
Reliability COMMERCIAL
Reference Standard UL, CSA
Number of Conductors ONE
Current Rating 18A
Orientation Vertical
Total Number of Contacts 6
Pitch 7.49mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Voltage - Rated DC 600V
Subcategory Headers and Edge Type Connectors
Fastening Type Ramp
Additional Feature SABRE, POLARIZED, POSITIVE LOCK
Gender Male
Number of Rows 1
Color Black
Min Operating Temperature -40°C
Max Operating Temperature 75°C
Number of Positions 6
Connector Type RECTANGULAR POWER CONNECTOR
ECCN Code EAR99
Termination Solder
Pbfree Code yes
JESD-609 Code e3
Packaging Bulk
Physical
Housing Material Thermoplastic
Insulation Material Nylon
Package / Case SMC
Mount Through Hole
Contact Plating Tin
Contact Material Brass
