RASM742TR
RoHS
/
Package SMD/SMT
Category Connectors, Interconnects / Barrel - Power Connectors
Description
CONN PWR JACK 1.05X3.5MM SOLDER
PDF
/
Inventory: 5805
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Technical
Rated Current (Power) 5A
Pin Diameter 1 mm
Actual Diameter 0.039 (1.00mm ID), 0.154 (3.90mm OD)
Industry Recognized Mating Diameter 1.05mm ID (0.041), 3.50mm OD (0.138)
Body Color Black
Internal Switch(s) Single Switch, Normally Closed
Number of Positions/Contacts 2 Conductors, 3 Contacts
Current Rating 3A
Shielding Unshielded
Option GENERAL PURPOSE
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating NOT SPECIFIED
Gender Male
Connector Type Jack
Termination Solder
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Obsolete
Published 2001
Packaging Tape & Reel (TR)
Physical
Contact Material - Plating Silver
Housing Material Thermoplastic
Package / Case SMD/SMT
Mounting Type Surface Mount, Right Angle
Mount Surface Mount
Contact Plating Nickel
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 6 Weeks
