RASH712
RoHS
/
Package /
Category Connectors, Interconnects / Barrel - Power Connectors
Description
DC Power Connectors JACK SMT 2.5MM
PDF
/
Buying Options
Total Price: USD $2.91
Unit Price: USD $2.90538
≥1 USD $2.90538
≥10 USD $2.740923
≥100 USD $2.585772
≥500 USD $2.43941
≥1000 USD $2.301335
Inventory: 7548
Minimum: 1
-
+
Technical Details
Technical
IEC Conformance NO
Option GENERAL PURPOSE
Orientation Right Angle
Shielding Unshielded
Depth 17.1mm
Current Rating 5A
Number of Contacts 2
Contact Gender Female
Insulation Resistance 30MOhm
Max Current Rating 5A
Number of Ports 1
Number of Positions/Contacts 2 Conductors, 3 Contacts
Internal Switch(s) Single Switch, Normally Closed
Body Color Black
Industry Recognized Mating Diameter 2.50mm ID (0.098), 5.50mm OD (0.217)
Actual Diameter 0.098 (2.50mm ID), 0.248 (6.30mm OD)
Rated Current (Power) 5A
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating SILVER
Gender Male
Connector Type Jack
Termination Solder
Number of Terminations 3
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Obsolete
Feature Board Guide
Published 2004
Packaging Bulk
Dimensions
Diameter 2.5mm
Length 15.2mm
Compliance
RoHS Status Non-RoHS Compliant
Flammability Rating UL94 V-0
Lead Free Contains Lead
Physical
Contact Material - Plating Tin
Body Material Copper Alloy
Housing Material Thermoplastic
Mounting Type Surface Mount, Right Angle; Through Hole
Mount Surface Mount, Through Hole
Contact Plating Nickel
Contact Material Brass
