EJ503A image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Barrel - Power Connectors
Description CONN PWR JACK 2.1X5.5MM SOLDER
PDF
/
Buying Options
Total Price: USD $1.21
Unit Price: USD $1.2144
≥1 USD $1.2144
≥10 USD $1.02344
≥100 USD $0.981728
≥500 USD $0.960784
≥1000 USD $0.918984
≥3000 USD $0.835472
Inventory: 1499
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status RoHS Compliant

Technical

Actual Diameter 0.083 (2.10mm ID), 0.217 (5.50mm OD)
Industry Recognized Mating Diameter 2.10mm ID (0.083), 5.50mm OD (0.217)
Body Color Black
Internal Switch(s) Single Switch, Normally Closed
Number of Positions/Contacts 2 Conductors, 3 Contacts
Shielding Unshielded
Current Rating (Amps) 5A
Voltage - Rated 12VDC
Gender Male
Connector Type Jack
Termination Solder Eyelet(s)
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Published 2014
Packaging Bulk
Operating Temperature -15°C~90°C

Physical

Contact Material - Plating Silver
Housing Material Polybutylene Terephthalate (PBT)
Mounting Type Through Hole, Right Angle
Contact Material Brass

Supply Chain

Factory Lead Time 14 Weeks
