RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Barrel - Power Connectors
Description
CONN PWR JACK 2.5X5.5MM SOLDER
PDF
/
Buying Options
Total Price: USD $1.25
Unit Price: USD $1.2496
≥1 USD $1.2496
≥10 USD $1.0868
≥100 USD $1.04016
≥500 USD $1.017104
≥1000 USD $0.970948
≥3000 USD $0.87846
Inventory: 5743
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Contact Material Brass, Copper Alloy
Contact Plating Nickel
Mount Chassis Mount
Mounting Type Chassis Mount
Mounting Feature Bulkhead - Front Side Nut
Housing Material Nylon
Body Material Brass
Contact Material - Plating Silver
Technical
Operating Temperature -15°C~90°C
Packaging Bulk
Published 2005
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder Eyelet(s)
Connector Type Jack
Max Operating Temperature 90°C
Min Operating Temperature -15°C
Color Black
Gender Male
Voltage - Rated 12VDC
Current Rating (Amps) 5A
Shielding Unshielded
Current Rating 5A
Housing Color Black
Thread Size M8x0.75
Number of Positions/Contacts 2 Conductors, 2 Contacts
Includes 3 pcs - 1 Connector, 1 Nut, 1 Washer
Internal Switch(s) Single Switch, Normally Closed
Body Color Silver
Industry Recognized Mating Diameter 2.50mm ID (0.098), 5.50mm OD (0.217)
Actual Diameter 0.098 (2.50mm ID), 0.220 (5.60mm OD)
Compliance
RoHS Status RoHS Compliant
