PP-002D
RoHS
/
Package /
Category Connectors, Interconnects / Barrel - Power Connectors
Description
Barrel Power Connector
PDF
/
Inventory: 7895
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Diameter 1.3mm
Technical
Mating Length/Depth 0.374 9.50mm
Actual Diameter 0.051 (1.30mm ID), 0.138 (3.50mm OD)
Industry Recognized Mating Diameter 1.30mm ID (0.051), 3.50mm OD (0.138)
Body Color Silver, Black
Internal Switch(s) Does Not Contain Switch
Includes 2 pcs - 1 Connector, 1 Handle
Number of Positions/Contacts 2 Conductors, 2 Contacts
Housing Color Black
Insulation Color Black
Current Rating 5A
Shielding Unshielded
Current Rating (Amps) 5A
Voltage - Rated 24VDC
Gender Female
Color Black
Min Operating Temperature 0°C
Max Operating Temperature 40°C
Connector Type Plug
Termination Solder Eyelet(s)
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Obsolete
Published 2002
Packaging Bulk
Operating Temperature 0°C~40°C
Physical
Contact Material - Plating Nickel
Body Material Brass
Housing Material Polyvinyl Chloride (PVC)
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Plating Nickel
Contact Material Brass
