PJ-202B
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Barrel - Power Connectors
Description
CONN PWR JACK 2.5X5.5MM SOLDER
PDF
/
Buying Options
Total Price: USD $0.72
Unit Price: USD $0.718174
≥1 USD $0.718174
≥10 USD $0.702477
≥100 USD $0.692011
Inventory: 10
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Contact Material Brass, Copper Alloy
Contact Plating Nickel
Mount Through Hole
Mounting Type Through Hole, Right Angle
Housing Material Polybutylene Terephthalate (PBT)
Contact Material - Plating Tin
Technical
Operating Temperature -25°C~85°C
Packaging Bulk
Published 2005
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Kinked Pin, Solder Eyelet
Connector Type Jack
Max Operating Temperature 85°C
Min Operating Temperature -25°C
Color Black
Gender Male
Voltage - Rated 24VDC
Current Rating (Amps) 2.5A
Orientation Horizontal
Shielding Unshielded
Current Rating 2.5A
Number of Conductors 2
Contact Gender Male
Housing Color Black
Insulation Resistance 100MOhm
Number of Positions/Contacts 2 Conductors, 3 Contacts
Internal Switch(s) Single Switch, Normally Closed
Body Color Black
Industry Recognized Mating Diameter 2.50mm ID (0.098), 5.50mm OD (0.217)
Actual Diameter 0.098 (2.50mm ID), 0.256 (6.50mm OD)
Mating Length/Depth 0.354 9.00mm
Dimensions
Diameter 2.5mm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
Lead Free Lead Free
