PJ-081AH
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Barrel - Power Connectors
Description
RoHS Compliant Single Switch Normally Closed Board Guide Male Barrel Power Connector -25C~85C 5A 24VDC 0.079 (2.00mm ID) 0.232 (5.90mm OD)
PDF
/
Buying Options
Total Price: USD $1.62
Unit Price: USD $1.6192
≥1 USD $1.6192
≥10 USD $1.40536
≥100 USD $1.345696
≥500 USD $1.315952
≥1000 USD $1.256112
≥3000 USD $1.136502
Inventory: 664
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Contact Material Brass, Copper Alloy
Mounting Type Through Hole, Right Angle
Housing Material Polyamide (PA10T), Nylon 10T
Contact Material - Plating Silver
Technical
Operating Temperature -25°C~85°C
Packaging Tape & Reel (TR)
Feature Board Guide
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Solder
Connector Type Jack
Gender Male
Voltage - Rated 24VDC
Current Rating (Amps) 5A
Shielding Shielded
Number of Positions/Contacts 2 Conductors, 3 Contacts
Internal Switch(s) Single Switch, Normally Closed
Body Color Silver, Black
Industry Recognized Mating Diameter 2.00mm ID (0.079), 5.50mm OD (0.217)
Actual Diameter 0.079 (2.00mm ID), 0.232 (5.90mm OD)
Mating Length/Depth 0.323 8.20mm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
