PJ-038A
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Barrel - Power Connectors
Description
CONN PWR JACK 2X5.5MM SOLDER
PDF
/
Buying Options
Total Price: USD $0.59
Unit Price: USD $0.5896
≥1 USD $0.5896
≥10 USD $0.4972
≥100 USD $0.405636
≥500 USD $0.324518
≥1000 USD $0.28395
≥3000 USD $0.269755
Inventory: 2902
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Material Flammability Rating UL94 V-0
Technical
Mating Length/Depth 0.354 9.00mm
Actual Diameter 0.079 (2.00mm ID), 0.244 (6.20mm OD)
Industry Recognized Mating Diameter 2.10mm ID (0.083), 5.50mm OD (0.217)
Body Color Black
Internal Switch(s) Single Switch, Normally Closed
Number of Positions/Contacts 2 Conductors, 3 Contacts
Insulation Resistance 100MOhm
Housing Color Black
Contact Gender Male
Number of Conductors 2
Current Rating 2.5A
Shielding Unshielded
Orientation Horizontal
Current Rating (Amps) 2.5A
Voltage - Rated 24VDC
Gender Male
Color Black
Min Operating Temperature -25°C
Max Operating Temperature 85°C
Connector Type Jack
Termination Solder Eyelet(s)
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Published 2011
Packaging Bulk
Operating Temperature -25°C~85°C
Physical
Contact Material - Plating Tin
Housing Material Polybutylene Terephthalate (PBT)
Mounting Feature Flange
Mounting Type Panel Mount
Mount Flanges, Panel
Contact Plating Nickel
Contact Material Brass, Copper Alloy
Supply Chain
Factory Lead Time 11 Weeks
