UJ4B
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Barrel - Audio Connectors
Description
CONN JACK STEREO 4.39MM PNL MNT
PDF
/
Buying Options
Total Price: USD $5.68
Unit Price: USD $5.676
≥1 USD $5.676
≥10 USD $5.1084
≥100 USD $4.812544
≥500 USD $4.689168
≥1000 USD $4.565704
≥3000 USD $4.345
Inventory: 413
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Length 27.78mm
Technical
Signal Lines Stereo (3 Conductor, TRS)
Actual Diameter 0.177 (4.48mm)
Industry Recognized Mating Diameter 4.39mm (0.173)
Body Color Silver, Black
Internal Switch(s) Two Switches
Includes 3 pcs - 1 Connector, 1 Nut, 1 Washer
Number of Positions/Contacts 3 Conductors, 5 Contacts
Thread Size 9/32-32
Number of Ports 1
Empty Shell YES
Mating Information MULTIPLE MATING PARTS AVAILABLE
Depth 11.9mm
Shielding Unshielded
Orientation Straight
Total Number of Contacts 3
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Gender Female
Color Black
Connector Type Phone Jack
ECCN Code EAR99
Termination Solder Eyelet(s)
Number of Terminations 3
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Feature Mounting Hardware, Thread Lock
JESD-609 Code e4
Series UNIJAX?
Published 2005
Packaging Bulk
Physical
Body Material Copper Alloy
Housing Material Thermoplastic
Shell Material POLYETHYLENE
Mounting Type Panel Mount
Mount Chassis Mount, PCB, Panel
Contact Plating Silver
Contact Material Brass; Copper Alloy
Supply Chain
Factory Lead Time 8 Weeks
