SN70C12B
RoHS
RoHS compliant
RoHS compliantPackage Metal
Category Connectors, Interconnects / Barrel - Audio Connectors
Description
Stereo (3Conductor TRS) SN70C ROHS3Compliant 2005 Phone Jack Connector 500V 0.250 (6.35mm)
PDF
/
Inventory: 10004
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Length 15.87mm
Technical
Signal Lines Stereo (3 Conductor, TRS)
Actual Diameter 0.250 (6.35mm)
Industry Recognized Mating Diameter 6.35mm (0.250, 1/4) - Headphone
Body Color Black
Internal Switch(s) Does Not Contain Switch
Includes 3 pcs - 1 Connector, 1 Nut, 1 Washer
Number of Positions/Contacts 3 Conductors, 3 Contacts
Thread Size 3/8-32
Number of Poles 3
Number of Ports 1
Number of Contacts 3
Shielding Unshielded
Orientation Right Angle
Pitch 7.62mm
Option GENERAL PURPOSE
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating NOT SPECIFIED
Additional Feature LOW PROFILE, 94V-0
Voltage - Rated 500V
Gender Female
Connector Type Phone Jack
Termination Solder
Number of Terminations 6
Part Status Active
Feature Mounting Hardware, Thread Lock
Series SN70C
Published 2005
Packaging Bulk
Physical
Contact Material - Plating Nickel
Housing Material Thermoplastic
Package / Case Metal
Mounting Type Through Hole, Right Angle
Mount Through Hole
Contact Plating Nickel, Silver, Tin
Contact Material Brass
Supply Chain
Factory Lead Time 12 Weeks
