S830
RoHS
RoHS compliant
RoHS compliantPackage Metal
Category Connectors, Interconnects / Barrel - Audio Connectors
Description
Conn 1/4" Extension Jack F 3 POS Solder ST Cable Mount 3 Terminal 1 Port
PDF
/
Buying Options
Total Price: USD $14.51
Unit Price: USD $14.5112
≥1 USD $14.5112
≥10 USD $12.70984
≥100 USD $12.160544
≥500 USD $12.107216
Inventory: 155
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Contact Material Copper Alloy
Contact Plating Nickel, Tin
Mount Cable, Free Hanging
Mounting Type Free Hanging (In-Line)
Package / Case Metal
Housing Material Thermoplastic
Body Material Brass
Contact Material - Plating Nickel
Technical
Packaging Bulk
Series Extension Jax?
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Number of Terminations 3
Termination Screw
Connector Type Phone Jack
Max Operating Temperature 125°C
Min Operating Temperature -55°C
Color Black
Gender Female
Contact Finish - Mating NOT SPECIFIED
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Option GENERAL PURPOSE
Orientation Straight
Shielding Unshielded
Number of Ports 1
Number of Poles 3
Cable Opening 0.280 (7.10mm)
Number of Positions/Contacts 3 Conductors, 3 Contacts
Includes 3 pcs - 1 Connector, 1 Nut, 1 Washer
Internal Switch(s) Does Not Contain Switch
Outside Diameter 6.35 mm
Body Color Silver, Black
Industry Recognized Mating Diameter 5.23mm (0.206)
Actual Diameter 0.210 (5.33mm)
Signal Lines Stereo (3 Conductor, TRS)
Dimensions
Length 54.8mm
Compliance
REACH SVHC Unknown
RoHS Status ROHS3 Compliant
Lead Free Lead Free
