RTTC8705
RoHS
/
Package /
Category Connectors, Interconnects / Barrel - Audio Connectors
Description
Barrel Audio Connector
PDF
/
Inventory: 9431
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Copper Alloy
Mount Through Hole
Mounting Type Through Hole, Right Angle
Housing Material Thermoplastic
Contact Material - Plating Gold
Technical
Operating Temperature -55°C~85°C
Published 1998
Series RTTC
JESD-609 Code e4
Feature Cover
Part Status Obsolete
Moisture Sensitivity Level (MSL) Not Applicable
Termination Solder
Connector Type Phone Jack, Twin
Gender Female
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Option GENERAL PURPOSE
Shielding Unshielded
Insulation Color White
Configuration 1X1 HORIZONTAL
Number of Ports 1
Number of Poles 3
Number of Positions/Contacts 2 Sets of 3 Conductors, 10 Contacts
Includes 2 pcs - 1 Connector, 1 Cover
Internal Switch(s) 2 Sets of Two Switches
Industry Recognized Mating Diameter 4.39mm (0.173)
Actual Diameter 0.177 (4.48mm)
Signal Lines Stereo (3 Conductor, TRS)
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
