RA70B11
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Barrel - Audio Connectors
Description
Conn 1/4" Phone Jack F 2 POS 7.62mm Solder RA Thru-Hole 4 Terminal 1 Port
PDF
/
Inventory: 1410
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Length 15.74mm
Technical
Signal Lines Mono
Actual Diameter 0.253 (6.43mm)
Industry Recognized Mating Diameter 6.35mm (0.250, 1/4) - Headphone
Internal Switch(s) Does Not Contain Switch
Includes 3 pcs - 1 Connector, 1 Nut, 1 Washer
Number of Positions/Contacts 2 Conductors, 2 Contacts
Thread Size 3/8-32
Number of Poles 2
Number of Ports 1
Housing Color Black
Number of Contacts 2
Depth 34.03mm
Shielding Unshielded
Orientation Right Angle
Pitch 7.62mm
Option GENERAL PURPOSE
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating NOT SPECIFIED
Gender Female
Connector Type Phone Jack
ECCN Code EAR99
Termination Solder
Number of Terminations 4
Part Status Active
Feature Board Guide
Series RA Jax?
Published 2007
Packaging Bulk
Physical
Contact Material - Plating Silver
Housing Material Thermoplastic, Polyester
Mounting Type Through Hole, Right Angle
Mount Through Hole
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 12 Weeks
