MT336C
RoHS
/
Package /
Category Connectors, Interconnects / Barrel - Audio Connectors
Description
CONN JACK STEREO 6.35MM PNL MNT
PDF
/
Inventory: 3495
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Contact Material Palladium (Pd)
Mount Panel
Mounting Type Panel Mount
Number of Pins 3
Body Material Steel
Contact Material - Plating Gold
Technical
Operating Temperature -20°C~65°C
Packaging Bulk
Published 1998
Series MT-JAX?
Feature Grounding Tab
Part Status Active
Termination Solder Eyelet(s)
Connector Type Phone Jack
Color Black
Gender Female
Voltage - Rated 500V
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Option GENERAL PURPOSE
Shielding Unshielded
Configuration 1X1 HORIZONTAL
Number of Ports 1
Number of Poles 3
Number of Positions/Contacts 3 Conductors, 7 Contacts
Internal Switch(s) Two Switches
Body Color Silver
Industry Recognized Mating Diameter 6.35mm (0.250, 1/4) - Headphone
Actual Diameter 0.252 (6.40mm)
Signal Lines Stereo (3 Conductor, TRS)
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
