RoHS
/
Package /
Category Connectors, Interconnects / Barrel - Audio Connectors
Description Barrel Audio Connector
PDF
/
Inventory: 4250
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Contact Material Brass
Mount Panel, Through Hole
Mounting Type Panel Mount, Through Hole
Housing Material Thermoplastic
Contact Material - Plating Tin

Technical

Published 1998
Series Hi-D JAX? MN-11*
Feature Mounting Hardware, Thread Lock
Part Status Obsolete
Moisture Sensitivity Level (MSL) Not Applicable
Termination Solder
Connector Type Phone Jack
Gender Female
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Shielding Unshielded
Thread Size 3/8-32
Number of Positions/Contacts 3 Conductors, 5 Contacts
Includes 3 pcs - 1 Connector, 1 Nut, 1 Washer
Internal Switch(s) Two Switches
Body Color Black
Panel Hole Size 0.375 9.52mm
Industry Recognized Mating Diameter 6.35mm (0.250, 1/4) - Headphone
Actual Diameter 0.250 (6.35mm)
Signal Lines Stereo (3 Conductor, TRS)

Compliance

RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
