MN114B
RoHS
/
Package /
Category Connectors, Interconnects / Barrel - Audio Connectors
Description
Barrel Audio Connector
PDF
/
Inventory: 4291
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Technical
Signal Lines Stereo (3 Conductor, TRS)
Actual Diameter 0.250 (6.35mm)
Industry Recognized Mating Diameter 6.35mm (0.250, 1/4) - Headphone
Panel Hole Size 0.375 9.52mm
Body Color Black
Internal Switch(s) Two Switches
Includes 3 pcs - 1 Connector, 1 Nut, 1 Washer
Number of Positions/Contacts 3 Conductors, 5 Contacts
Thread Size 3/8-32
Shielding Unshielded
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Gender Female
Connector Type Phone Jack
Termination Solder Eyelet(s)
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Obsolete
Feature Mounting Hardware, Thread Lock
Series Hi-D JAX? MN-11*
Published 1998
Physical
Contact Material - Plating Tin
Housing Material Thermoplastic
Mounting Type Panel Mount, Through Hole
Mount Panel, Through Hole
Contact Material Brass
