BPJR05X
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Barrel - Audio Connectors
Description
CONN RCA JACK MONO 3.2MM PNL MT
PDF
/
Buying Options
Total Price: USD $1.15
Unit Price: USD $1.151413
≥1 USD $1.151413
≥200 USD $0.446386
≥500 USD $0.430631
≥1000 USD $0.422754
Inventory: 7000
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Contact Plating Nickel, Silver
Mount Panel
Mounting Type Panel Mount
Body Material Brass
Contact Material - Plating Nickel
Technical
Packaging Bulk
Published 2005
Feature Grounding Tab, Mounting Hardware
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Solder Eyelet(s)
Connector Type Phono (RCA) Jack
Gender Female
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Option GENERAL PURPOSE
Shielding Unshielded
Insulation Color Blue
Number of Ports 1
Number of Poles 2
Thread Size 3/8-32
Number of Positions/Contacts 2 Conductors, 2 Contacts
Includes 3 pcs - 1 Connector, 1 Nut, 1 Washer
Internal Switch(s) Does Not Contain Switch
Body Color Silver
Panel Hole Size 0.375 9.52mm
Industry Recognized Mating Diameter 3.20mm ID, 9.00mm OD (RCA)
Actual Diameter 0.134 (3.40mm ID), 0.325 (8.25mm OD)
Signal Lines Mono
Compliance
RoHS Status ROHS3 Compliant
