BPJR01X
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Barrel - Audio Connectors
Description
Conn RCA F 2 POS Solder ST Panel Mount 2 Terminal 1 Port
PDF
/
Buying Options
Total Price: USD $2.1
Unit Price: USD $2.1032
≥1 USD $2.1032
≥10 USD $1.9096
≥100 USD $1.808224
≥500 USD $1.766336
≥1000 USD $1.682208
≥3000 USD $1.47195
Inventory: 1047
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Length 21.6mm
Technical
Signal Lines Mono
Actual Diameter 0.134 (3.40mm ID), 0.325 (8.25mm OD)
Industry Recognized Mating Diameter 3.20mm ID, 9.00mm OD (RCA)
Panel Hole Size 0.375 9.52mm
Body Color Silver
Internal Switch(s) Does Not Contain Switch
Includes 3 pcs - 1 Connector, 1 Nut, 1 Washer
Number of Positions/Contacts 2 Conductors, 2 Contacts
Thread Size 3/8-32
Number of Poles 2
Number of Ports 1
Insulation Color Black
Depth 13mm
Shielding Unshielded
Orientation Straight
Option GENERAL PURPOSE
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Gender Female
Connector Type Phono (RCA) Jack
Termination Solder Eyelet(s)
Number of Terminations 2
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Feature Grounding Tab, Mounting Hardware
Published 2005
Packaging Bulk
Physical
Contact Material - Plating Nickel
Body Material Brass
Mounting Type Panel Mount
Mount Panel
Contact Plating Nickel, Silver
Supply Chain
Factory Lead Time 8 Weeks
