597
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Barrel - Audio Connectors
Description
Barrel Audio Connector
PDF
/
Buying Options
Total Price: USD $0.19
Unit Price: USD $0.1936
≥1 USD $0.1936
≥10 USD $0.164032
≥100 USD $0.152592
≥500 USD $0.144109
≥1000 USD $0.129976
≥3000 USD $0.109657
Inventory: 30118
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Technical
Mating Length/Depth 1.200 30.50mm
Signal Lines Stereo (3 Conductor, TRS)
Actual Diameter 0.250 (6.35mm)
Industry Recognized Mating Diameter 6.35mm (0.250, 1/4) - Headphone
Body Color Silver
Internal Switch(s) Does Not Contain Switch
Includes 3 pcs - 1 Connector, 1 Handle, 1 Insulator Tube
Number of Positions/Contacts 3 Conductors, 3 Contacts
Cable Opening 0.297 (7.54mm)
Number of Poles 3
Number of Ports 1
Shielding Shielded
Orientation Straight
Option GENERAL PURPOSE
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating NOT SPECIFIED
Gender Male
Connector Type Phone Plug
Termination Solder
Number of Terminations 3
Part Status Active
JESD-609 Code e3
Packaging Bulk
Physical
Body Material Copper Alloy
Housing Material Zinc
Mounting Type Free Hanging (In-Line)
Mount Cable, Free Hanging
Contact Plating Tin
Supply Chain
Factory Lead Time 12 Weeks
