580
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Barrel - Audio Connectors
Description
Mono ROHS3Compliant Straight GENERAL PURPOSE Phone Plug Connector 0.250 (6.35mm)
PDF
/
Buying Options
Total Price: USD $5.45
Unit Price: USD $5.454233
≥1 USD $5.454233
≥10 USD $5.1455
≥100 USD $4.854242
≥500 USD $4.579476
≥1000 USD $4.320265
Inventory: 981
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Diameter 6.35mm
Technical
Mating Length/Depth 1.188 30.20mm
Signal Lines Mono
Actual Diameter 0.250 (6.35mm)
Industry Recognized Mating Diameter 6.35mm (0.250, 1/4) - Headphone
Internal Switch(s) Does Not Contain Switch
Includes 2 pcs - 1 Connector, 1 Handle
Number of Positions/Contacts 2 Conductors, 2 Contacts
Cable Opening 0.297 (7.54mm)
Number of Poles 2
Number of Ports 1
Insulation Color Red
Shielding Shielded
Orientation Straight
Option GENERAL PURPOSE
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating NOT SPECIFIED
Gender Male
Color Silver
Connector Type Phone Plug
Termination Solder
Number of Terminations 2
Part Status Active
JESD-609 Code e3
Packaging Bulk
Physical
Body Material Brass
Mounting Type Free Hanging (In-Line)
Mount Cable, Free Hanging
Contact Plating Tin
Contact Material COPPER ALLOY
Supply Chain
Factory Lead Time 12 Weeks
