482
RoHS
RoHS compliant
RoHS compliantPackage Metal
Category Connectors, Interconnects / Barrel - Audio Connectors
Description
Conn 1/4" Phone Plug PL 3 POS Screw ST Cable Mount 3 Terminal 1 Port
PDF
/
Buying Options
Total Price: USD $9.18
Unit Price: USD $9.1784
≥1 USD $9.1784
Inventory: 191
Minimum: 1
-
+
Technical Details
Physical
Contact Material Copper Alloy
Mount Cable
Mounting Type Free Hanging (In-Line)
Package / Case Metal
Housing Material Thermoplastic
Body Material Copper Alloy
Contact Material - Plating Tin
Technical
Packaging Bulk
Published 1999
Part Status Obsolete
Moisture Sensitivity Level (MSL) Not Applicable
Number of Terminations 3
Termination Screw
Connector Type Phone Plug
Number of Positions 2
Color Black
Gender Male
Contact Finish - Mating NOT SPECIFIED
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Option GENERAL PURPOSE
Orientation Straight
Shielding Shielded
Approval Agency UL
Number of Ports 1
Cable Length 52.8mm
Number of Poles 3
Number of Positions/Contacts 3 Conductors, 3 Contacts
Includes 4 pcs - 1 Connector, 1 Handle, 2 Screws
Internal Switch(s) Does Not Contain Switch
Body Color Silver
Industry Recognized Mating Diameter 6.35mm (0.250, 1/4) - Headphone
Actual Diameter 0.250 (6.35mm)
Signal Lines Stereo (3 Conductor, TRS)
Mating Length/Depth 1.140 28.90mm
Dimensions
Length 81.78mm
Compliance
REACH SVHC Unknown
RoHS Status ROHS3 Compliant
Lead Free Lead Free
