480X
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Barrel - Audio Connectors
Description
CONN PLUG AUDIO PHONE 3COND BLK
PDF
/
Buying Options
Total Price: USD $26.44
Unit Price: USD $26.4352
≥1 USD $26.4352
≥10 USD $23.1528
≥100 USD $22.152064
≥500 USD $22.054912
Inventory: 1027
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Mating Length/Depth 1.090 27.70mm
Signal Lines Stereo (3 Conductor, TRS)
Actual Diameter 0.207 (5.26mm)
Industry Recognized Mating Diameter 5.23mm (0.206)
Body Color Gold, Black
Internal Switch(s) Does Not Contain Switch
Includes 5 pcs - 1 Connector, 1 Handle, 3 Screws
Number of Positions/Contacts 3 Conductors, 3 Contacts
Cable Opening 0.297 (7.54mm)
Number of Ports 1
Housing Color Black
Approval Agency UL
Shielding Shielded
Orientation Straight
Option GENERAL PURPOSE
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating TIN
Gender Male
Color Black, Natural
Connector Type Phone Plug
ECCN Code EAR99
Termination Screw
Number of Terminations 3
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code yes
Feature Internal Interlock
JESD-609 Code e3
Series LITTEL-PLUG? 480
Published 2008
Packaging Bulk
Physical
Contact Material - Plating Natural
Body Material Brass
Housing Material Thermoplastic
Mounting Type Free Hanging (In-Line)
Mount Cable, Free Hanging
Contact Plating Tin
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 12 Weeks
