35RAPC7J image
Favorite
35RAPC7J image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Barrel - Audio Connectors
Description Conn Stereo Jack F/F 2/2 POS Solder RA Thru-Hole 4 Terminal 1 Port
PDF
/
Buying Options
Total Price: USD $4.08
Unit Price: USD $4.075242
≥1 USD $4.075242
≥200 USD $1.576793
≥500 USD $1.521651
≥1000 USD $1.49408
Inventory: 5005
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 8 Weeks

Physical

Contact Material Copper Alloy
Contact Plating Nickel, Silver
Mount Through Hole
Mounting Type Through Hole, Right Angle
Number of Pins 1
Housing Material Liquid Crystal Polymer (LCP)
Body Material Copper Alloy
Contact Material - Plating Silver

Technical

Packaging Bulk
Published 2008
Series 35
JESD-609 Code e4
Part Status Active
Number of Terminations 4
Termination Solder
Connector Type Phone Jack
Color Black
Gender Female
Voltage - Rated 500V
Additional Feature LCP
Contact Finish - Mating NOT SPECIFIED
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Option GENERAL PURPOSE
Orientation Right Angle
Shielding Unshielded
Number of Ports 2
Number of Poles 3
Number of Positions/Contacts 2 Sets of 3 Conductors, 8 Contacts
Internal Switch(s) Two Switches
Body Color Silver, Black
Industry Recognized Mating Diameter 3.50mm (0.141, 1/8, Mini Plug) - Headphone
Actual Diameter 0.142 (3.60mm)
Signal Lines Stereo (3 Conductor, TRS)

Compliance

RoHS Status ROHS3 Compliant
Lead Free Lead Free

Alternative Model
